Anti-Reflection (AR) Coating Processing
Customization Supported: Yes
Shipping Location: Shenzhen, Guangdong Province, China
Brand: Dinghongrun
E-mail: dhr@dinghongrun.com
WhatsApp: +8613629515219
AR Coating Technology
Anti-Reflection (AR) coatings, also known as anti-reflective films, are specialized optical coatings applied to glass surfaces to enhance light transmission. By leveraging interference effects created by multiple dielectric layers, AR coatings minimize reflected light and maximize transmitted light intensity. This results in improved image clarity for optical systems.
Dinghongrun provides custom AR coating solutions including:
- Standard AR coatings
- Hybrid AR + DLC (Diamond-Like Carbon) coatings
Core Technologies
1. Standard AR Coatings
- Reduces/eliminates surface reflections on lenses, prisms, and mirrors
- Minimizes stray light in optical systems
- Available for:
- Visible spectrum (400-700nm)
- Near-IR (700-1300nm)
- Far-IR (8-12μm)
- Applications: Laser systems, fiber optics, precision instruments
2. AR + DLC Hybrid Coating
| Property | Benefit |
|---|---|
| DLC Coating Characteristics | |
| Hardness | 20-50 GPa (Vickers) |
| Friction Coefficient | 0.05-0.15 |
| IR Transmission | >90% at 3-5μm MWIR |
| Environmental Resistance | Salt spray/chemical corrosion protection |
| Hybrid Performance | |
| Substrates | Silicon, Germanium, IR materials |
| Coating Type | BBAR (Broadband AR) + DLC |
| Military Compliance | MIL-C-675C / MIL-F-48616 |
| Applications | Thermal imaging systems, defense optics, aerospace sensors |
Technical Advantages
- Precision Optics: <0.5% reflectance per surface at design wavelength
- Durability: Passes 50+ hours salt spray testing (ASTM B117)
- Customization:
- Target wavelength optimization
- Incidence angle adjustment (0-45°)
- Environmental hardening
Contact us for application-specific coating solutions.
