Application of Dinghongrun optical elements in laser welding

​​Case Studies 420
Application of Dinghongrun optical elements in laser welding

The laser welding technology consists of an optical oscillator and a medium placed between the mirrors at both ends of the oscillator cavity. When the medium is excited to a high energy state, it starts to produce in-phase light waves and reflect back and forth between the mirrors at both ends, forming a photoelectric cascade effect, amplifying the light waves, obtaining enough energy and starting to emit laser. These laser beams have the characteristics of high concentration and single wavelength, and can provide welding, cutting, heat treatment and other functions after being highly concentrated. Dinghongrun Optical elements involved in laser welding include window piece lens , filter, reflector.

Optical elements required for laser welding

Window slice
Calcium fluoride window slice, barium fluoride window slice, magnesium fluoride window slice, silicon window slice, germanium window slice, zinc selenide window slice, zinc sulfide window slice, sapphire window slice, fused quartz window slice

lens
Flat convex lens, flat concave lens, biconcave lens, biconvex lens, meniscus lens

filter
Germanium long wave pass filter, silicon long wave pass filter

reflector

Application fields of laser welding
Automobile manufacturing, aerospace, electronic assembly, medical device manufacturing, jewelry industry, machinery manufacturing, construction, shipbuilding, petrochemical industry

Instruments required for laser welding
Laser generator, optical oscillator, pulse laser power supply of optical fiber laser welding machine, optical fiber transmission system, special cooling system, industrial television observation system, radiation parameter sensor, process medium transmission system, process parameter sensor
